JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery

JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery

Temperature Resistance Rubber Shock Absorber

50mm Width Vibration Isolator

30 Hz Resonance Frequency Friction Damping Vibration Isolator

원래 장소:

중국

브랜드 이름:

Hoan

모델 번호:

JZP-9.0-SC-SC1

저희와 연락
인용 을 요청 하십시오
제품 세부 정보
온도 저항:
섭씨 100도까지
너비:
50mm
재료:
고무
UV 저항:
강한
공명 주파수:
30 HZ
로드 용량:
100-5000파운드
장착 방향:
수직의
포장:
표준 포장
축 강성:
50n/mm
진동 주파수:
5Hz ~ 100Hz
품질:
산업 등급
마케팅 유형:
핫 제품 2024
용법:
산업 기계
강조하다:

Temperature Resistance Rubber Shock Absorber

,

50mm Width Vibration Isolator

,

30 Hz Resonance Frequency Friction Damping Vibration Isolator

지불 및 배송 조건
최소 주문 수량
4
지불 조건
L/C, D/A, D/P, T/T, Western Union, MoneyGram
제품 설명
JZP-9.0-SC-SC1 Rubber Shock Absorber - Essential Component for Industry 4.0 Smart Production Lines
JZP-SC-SC1 Series: The Efficiency Multiplier for Smart Manufacturing
Under Industry 4.0 frameworks, production line intelligence and high throughput demand unprecedented equipment stability. The JZP-SC-SC1 series friction damping vibration isolators from Xi'an Hoan Microwave serve as critical "efficiency multipliers" for smart production lines.
Key Performance Advantages:
  • Effectively mitigates transient impacts and wide-frequency vibrations from industrial robots and AGV systems
  • Maintains positioning accuracy for precision assembly robots
  • Ensures clear imaging for visual inspection systems
  • Reduces quality issues like connector insertion failures
  • High damping characteristics enable rapid equipment stabilization between movements
  • Robust, maintenance-free design meets industrial reliability requirements
By implementing JZP-SC-SC1 isolators, manufacturers achieve not just vibration control but complete production process optimization - enabling truly efficient, high-reliability "dark factory" operations.
Dimension Specifications
JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery 0
Model D (mm) H±1 (mm) h (mm) A±0.2 (mm) B (mm) d d2 R b (mm)
JZP-SC-SC1 60 36 24.5 50 60 M5 ∅5.5 5 28
Technical Parameters
Model Nominal Load (KG) Static Displacement (mm) Working Temperature (℃) Resonance Frequency (Hz) Impact Test Limited Period
JMZ-3.2-SC-SC1 3.2 ≤0.3 -45~+65 41.5±5 100g 12 times 8
JMZ-4.2-SC-SC1 4.2 ≤0.3 -45~+65 41.5±5 100g 12 times 8
JMZ-5.2-SC-SC1 5.2 ≤0.3 -45~+65 41.5±5 100g 12 times 8
JMZ-6.0-SC-SC1 6.0 ≤0.3 -45~+65 41.5±5 100g 12 times 8
JMZ-7.0-SC-SC1 7.0 ≤0.3 -45~+65 41.5±5 100g 12 times 8
JZP-7.5-SC-SC1 7.5 ≤0.3 -45~+65 41.5±5 100g 12 times 8
JZP-9.0-SC-SC1 9.0 ≤0.3 -45~+65 41.5±5 100g 12 times 8
JZP-10.5-SC-SC1 10.5 ≤0.3 -45~+65 41.5±5 100g 12 times 8
JZP-13.5-SC-SC1 13.5 ≤0.3 -45~+65 41.5±5 100g 12 times 8
JZP-15-SC-SC1 15 ≤0.3 -45~+65 41.5±5 100g 12 times 8
Customer Implementation
JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery 1
